Pinch Valves Series 78: Stainless Steel with Tri-Clamp

The Uncompromising Premium Valve with Tri-Clamp

Series 78 combines the highest material resistance with a hygienic design. Manufactured entirely from high-quality stainless steel 1.4404 and equipped with standardized Tri-Clamp connections (DIN 32676 Series A), this pinch valve meets the strict requirements of the pharmaceutical, chemical, and food industries. The combination with robust stainless steel screws (A4) makes it the uncompromising choice for sterile and chemically demanding processes. With appropriate sleeve qualities, this series is also available as an ATEX version for hazardous areas.

‍

Typical Applications

• Pharmaceutical processes
• Chemical industry
• Food and beverage industry
• ATEX applications

‍

Key Benefits

• Hygienic Tri-Clamp connection (DIN 32676 Series A)
• Housing and connections entirely made of stainless steel 1.4404
• Full bore product flow matching the nominal size
• No clogging, no constrictions, and no dead zones
• Lightning-fast opening and closing
• 100% leak-tight / gas-tight
• Maintenance-friendly valve with rapid sleeve replacement
• Assembled silicone-free as standard

‍

‍
